8 Ton caterpillar dump truck
1. High capacity: carrying capacity of 8 tons, suitable for large -scale engineering transportation, can transport a large number of materials at a time, reduce transportation time and increase efficiency.
2. Great cross -country ability: the design of caterpillars allows you to move around swamps, snow, mountains and other harsh areas, reduces pressure on the soil, does not drown and can get to where the wheel transport cannot get.
3. High adaptability: it can work stably in various climatic conditions and is suitable for transporting various materials, such as ore, slag, sand and gravel.
4. Good stability: heavy body and wide track provide good stability, preventing overturning, providing safe transportation at full load, especially suitable for uneven roads or inclined sections.
Product representation
Possessing high carrying capacity, excellent off -road characteristics and excellent stability, a caterpillar dump truck is especially suitable for large -scale engineering transportation. Its 8-ton carrying capacity allows you to transport a large number of materials at a time, reducing the time of transportation and increasing the efficiency of work. The caterpillar structure allows it to easily move in an impassable area (for example, swamps, snow and mountains), avoiding drifts and failures characteristic of wheeled equipment, and reaching places that are difficult to reach the wheeled equipment. At the same time, the caterpillar dump truck adapts to various climatic and environmental conditions, whether it is heat, cold or humidity, it can work stably and effectively transport various materials, such as ore, slag, sand and gravel. Heavy body and wide caterpillars provide it with good stability during loading, unloading and transportation, and it can avoid overturning when completely loading to ensure the safety of transportation, especially suitable for crossed or inclined areas.
Parameters
Engine model |
Engine 4102 with turbocharged |
engine power |
68KW |
Transmission model |
145 gearbox |
Transmission level |
5+1 gear an air impetus at high and low speeds |
Changing the direction |
steering |
Model of the rear axle |
1080 |
Caterpillar type |
400*90*68 |
Technical characteristics of the track |
Engineering caterpillar machine |
Method of braking |
Brake (when moving) |
The size of the cabin |
2600*2000*600mm |
The thickness of the steel sheet in carriage |
Bottom 3 side 2 |
Car size |
4200*2000*2200mm |
Unloading method |
Hydraulic self -discharge |
Cabins |
Single closed cab |
The material of the running wheel |
Vajra wheels (whole front and back) |
The tension method |
The tension of the screw |
watering can |
Electronic bucket for scooping |
speed of movement |
3-30km/h |
The angle of rise |
35 ° |
The length of the path |
2700mm |
Houck |
Air beep |
The position of the driver |
Left -handed movement (optionally - right -handed) |
battery |
24V |
Exhibition cabinets
Acquaintance with the plant
The company has created a perfect quality management system, starting from checking the purchase of raw materials, checking and selecting samples in the production process, and ending with strict testing of finished products before leaving the factory, each link of careful quality control to guarantee that each exported construction equipment may correspond to or exceed international quality standards in order to provide customers with excellent product quality.
