Komatsu 6136-32-2110 piston 4D105

Product Introduction

Product Details

Material: Typically made of high-strength aluminum alloy, it boasts lightweight properties and good thermal conductivity. This can effectively reduce engine weight and improve fuel economy. At the same time, good thermal conductivity helps quickly dissipate heat, reducing piston operating temperatures and extending service life. Some high-performance models may use special coatings on the piston surface, such as molybdenum coating, to enhance wear and corrosion resistance.

Structure: Consists of three parts: the piston crown, the piston skirt, and the piston pin bore. The piston crown is the main part that receives gas pressure and typically features recesses or projections of various shapes to optimize combustion; the piston skirt contacts the cylinder wall, acting as a guide and support, and typically has a certain curvature and clearance to compensate for thermal expansion; the piston pin bore is used to install the piston pin, connect the piston and connecting rod, and transmit power.

Size: Various sizes are available to suit the requirements of different Komatsu engine models. For example, the piston diameter of a Komatsu PC200-8 excavator engine is likely to be around 100 mm, and the piston height will range from 120 mm to 150 mm.

Performance parameters: Taking the piston of Komatsu WA380-3 engine as an example, the maximum explosion pressure it can withstand can reach about 15-20 MPa, and the reciprocating speed of the piston can reach a relatively high level under the rated speed of the engine, usually 8 to 12 m/s.

Installation steps

Preparation: Prepare tools such as piston ring compressor, connecting rod bolt wrench, special tools for disassembling and assembling cylinder liners, micrometer for measuring the inner diameter, etc. Clean the internal parts of the engine, remove carbon deposits and dirt, check if there are any scratches or wear on the cylinder walls.

Install the piston ring: Insert the piston rings one by one into the piston ring grooves, making sure the piston ring holes are offset by 120°, and apply a small amount of engine oil to the top of the piston.

Assemble the piston and connecting rod: place the small end of the connecting rod on the piston pin, press and lock it with a special tool, make sure the piston pin and the small end bore of the connecting rod are in good alignment, and measure the clearance between the piston skirt and the cylinder wall with an inside diameter micrometer.

Install the connecting rod cap and bolts: Align the connecting rod cap with the big end of the connecting rod and tighten it with the connecting rod bolts, following the principle of "gradually tighten from the middle to both sides several times."

Install the piston: Place the assembled piston assembly into the cylinder, compress it using a piston ring compressor, gently rotate the crankshaft by hand until the piston reaches bottom dead center, and recheck the clearance between the piston skirt and the cylinder wall.

Common faults

Piston wear: including piston skirt wear, piston ring groove wear, piston top wear, etc. Causes may include: insufficient lubrication, incomplete combustion, excessive thermal load, mechanical impurities, improper assembly, etc.

Piston distortion: Pistons are subject to thermal distortion under high temperatures and pressures, which leads to changes in cylinder wall clearance and increased wear. The main causes are excessive thermal loads caused by cooling system malfunctions and poor combustion chamber design.

Seized or broken piston ring: A seized or broken piston ring may cause engine leakage and reduced compression pressure due to carbon accumulation, insufficient lubrication, etc.; a broken piston ring can also cause similar problems, which may be caused by poor piston ring quality, improper assembly, etc.

Piston Surface Cracks or Ablation: Piston surface cracks affect strength and sealing, and ablation increases wear, typically due to excessive thermal load, stress concentration, poor fuel quality, etc.

After sales service

Warranty Service: Komatsu engine pistons are typically covered by a warranty for a specified period, typically one year or a specified number of operating hours, whichever comes first. During the warranty period, any defect or damage caused by non-human factors may be replaced or repaired free of charge.

Accessories Supply: Komatsu has a complete accessories supply system, which can supply genuine pistons and related accessories in a timely manner, ensuring the quality and compatibility of accessories.

Technical Support: Providing professional technical consulting services. If users encounter problems during installation, use, and maintenance, they can receive technical guidance through customer service hotlines, online consultations, and more.

Maintenance: We have a professional maintenance team and service centers nationwide that provide on-site service or return to the factory for repairs. Our service personnel can quickly diagnose and repair piston-related issues.

Regular follow-up visits: Regular follow-up visits to users to understand piston usage patterns and user needs, collect feedback and continuously improve products and services.

After-sales service for Komatsu engine pistons typically includes the following aspects:

Warranty service

Warranty Period: Generally, the warranty period is 1 year or a certain number of working hours (e.g. 2000 hours), whichever comes first.

Warranty Scope: During the warranty period, if the piston is damaged or defective due to non-human factors such as material defects, manufacturing process problems such as piston cracks, abnormal wear of piston ring, etc., Komatsu will repair or replace it free of charge.

Supply of accessories

Genuine Accessories: Please ensure that the pistons and related accessories provided are genuine Komatsu products, ensuring compatibility and matching with the engine, reliable quality and effective maintenance of engine performance.

Timely delivery: Thanks to a comprehensive logistics distribution network and spare parts inventory management system, we can quickly respond to customer needs, supply necessary spare parts in a timely manner, and reduce equipment downtime.

Technical support

Consulting services: Provide users with professional technical advice and answers to questions about piston installation, use, maintenance, troubleshooting, etc. Support is available through the customer service hotline, email, online customer service, and other channels.

Training Services: Technical training courses are conducted regularly or occasionally for large enterprise customers or professional maintenance personnel to explain the design principles, maintenance methods and points, and other knowledge of Komatsu engine pistons to improve users' maintenance capabilities.

Repair services

On-site maintenance: In certain emergency situations or for large equipment, Komatsu will arrange for professional personnel to perform on-site maintenance, quickly diagnose and repair piston and engine problems, and restore equipment operation.

Factory Repair: For complex malfunctions or situations requiring more specialized equipment and technology, the piston or engine can be returned to the factory for repair. Following repair, rigorous testing and quality assurance will be performed to ensure compliance with factory standards.

Repair quality guarantee

Quality Control: Refurbished pistons and engines undergo strict quality control and testing, including pressure testing, leakage testing, performance testing, etc., to ensure the quality of the repair.

After-sales follow-up: Follow-up with the user after maintenance to understand the piston usage and working condition of the equipment, collect feedback, and solve possible problems in a timely manner.

Emergency response services

24-hour service hotline: Establish a 24-hour after-sales service hotline to respond to customer fault reports and emergency requests at any time, ensuring that support is provided as quickly as possible.

Emergency Parts Reserve: For some wear parts and key components such as pistons, an emergency spare parts reserve is established so that they can be quickly deployed in an emergency to meet customer maintenance needs.
